Name: Factory Supplier High Speed Ultra-fast Jumbo Twist Chemical Fiber Cotton Yarn Wrapping Machine Double Bundle Winding Winder
Brand: Factory Supplier High Speed Ultra-fast Jumbo Twist Chemical Fiber Cotton Yarn Wrapping Machine Double Bundle Winding Winder
SKU: ZW230.280
Rating: 4.6 (171 reviews)

Χαρακτηριστικά Εκθεσιακός χώρος Περιγραφή προϊόντων Ζητήστε ένα απόσπασμα

Χαρακτηριστικά

Προδιαγραφές

Condition: New

Application: Winding Yarns

Automatic Grade: Semi-automatic

Production Capacity: 300-1000m/min

Model Number: ZW230.280

Voltage: 380v/220v

Power: 90W/spindle

Dimension(L*W*H): 13700 (length) x1050 (width) x1650 (high) mm

Weight: 350kg

Warranty: 1 Year

After-sales Service Provided: Engineers available to service machinery overseas

Πιστοποίηση: ISO CE

Name: PRECISION WINDING MACHINE

Βασικές πληροφορίες

Πιστοποίηση: ISO CE

Model Number: ZW230.280

Πληρωμής & Αποστολής Όροι

Packaging Details: packaged form :export wooden packing package size: length 1890mm * width 820mm * high 1380mm per set

Supply Ability: 5000 Set/Sets per Year

Περιγραφή προϊόντων

Product parameters

ZW230.280 high-speed Jumbo pack winder, suitable for chemical fiber, cotton yarn, industrial filament, low elastic yarn, mop line, winding into a conical or cylindrical, for the use of the process, good shape, high work efficiency, has no edge collapsing phenomenon, reduce the labor intensity of the process, adapt to the high speed production.

1.winding drive: each spindle drive alone, VVVF;
2.winding speed and density: 300-800 M / min;
3.with the electronic yarn breakage self stop function;
4.yarn diameter and dynamic range: diameter less than 290mm. The dynamic range is 200mm, 250mm;
5.with a single spindle length function;

6.advanced touch screen type man-machine interface.

7.with anti hard edge and electronic anti overlap swing function;

Bobbin type	8" 10"(280mm-300mm)
Structure	Two sided machine, each (4-36) spindle
Current source	Three phase 380V 50/60HZ
Drive	Single spindle independent AC motor drive
Power consumption	0.18KW/spindle
Bobbin forming	Cylindrical(0°)/conical
Bobbin diameter	Max 200 and 300mm
Yarn speed	300-1000m/min
Electronic preventing overlapping device	Variable frequency control
Length counting device	Controlled and displayed by PLC
Yarn tension and waxer adjusting	Every spindle has a self-cleaning
Mechanical clean yarn device	Configuration of each spindle can be fine tuned mechanical cleaning knife
Yarn break control device	The spindle will stop when the yarn breaks by a yambreak control device
Governor	Frequency control
Electronic yarn cleaning device	Optional
Jointair	Optional
External dimensions	1850(length)×800(wide)×1650(high)mm 4 spindle size

Paoduct Showcase

HOT PRODUCTS

Company Profile

Haining JOVIAN Textile Machinery Co., Ltd is located in resort tide, leather capital of Haining City, Zhejiang Province. 5 kilometers from SHANGHAI-HANGZHOU express way and Hangjinqu (G60) express. Unique geographical advantage, with convenient transportation access.

JOVIAN is a comprehensive enterprise specialized in the research, development, sell and services. We covering an area of 20 acres, for modern standard workshop cover an area of about 3000square meters. We have the most edging facilities, and professional people of research, development, main production winding machine (ZW013 Type Precision Winder Machine, ZW016 Type High Speed Winding Machine, ZW280 Tpye ZW230 Type High-Speed Jumbo Pack Winder etc.) . ZW019 Type High Speed Doubling Machine, ZW015 Type Wool Spinning Winder, ZW0322 Type Doubling and Double-Twisting Machine Textile Wax and so on.
JOVIAN company attach importance to brand building, and formulate a complete set of scientific management systems. And we will continuous improvement and innovation, hope the science, management, quality, efficiency, integration into the every aspect of the business, improve the core competitiveness of the product and market resilience, to win a high admiration and is widely trusted at home and abroad.

Product Packging

Transport Payment

FAQ

Frequently Asked Questions

Q:What kind of work does your company do?
A:Our company is a professional manufacturer.We mainly dealing with many kinds of quilting machine,etc.accordance with customers' requirement.

Q:What are the advantages of your company?
A: We have many professional technical personnel.And we have more competitive prices,high quality
and better service than trading companies.

Q:What about your price?
A:Our price is very competitive because we are a factory.Please contact us if you are interested in
our products.
Q:What is your delivery time?
A:Within 20 days after receipt of down payment.

Q:What is your payment terms?
A:Telegraphic transfer (T/T),Letter of credit(L/C) etc.
