This device uses a computer CNC control system to precisely locate the spindle by CPLD decoding and speed measurement. It is also equipped with a stepper motor with a constant current chopper to drive the wiring. It is fast and precise and ensures the normal operation of the equipment. It is widely used in the production system of medium and small transformers, relays, communication coils, high voltage wire packages, power converters, stabilizers, and other products.
Functions and characteristics:
1. The data stores the paragraph 0~999 step.
2. It can reverse the winding at high speed.
3. The number of circles is accurate.
4. The problem information is saved automatically.
5. CNC can monitor and display production status.
6. The setting is simple and the operation is convenient.
Model | YSY-PW762 | YSY-PW764 | YSY-PW766 |
Windable Wire Diameter | φ0.04-0.8mm | φ0.03-0.6mm | φ0.03-0.6mm |
Max.winding width | 100mm | 100mm | 100mm |
Max. bobbin Diameter | 120mm | 120mm | 120mm |
Spindles | 2 | 4 | 6 |
Spreading motor | 24V Stepping Motor | 24V Stepping Motor | 24V Stepping Motor |
Winding motor | AC 750W | AC 750W | AC 750W |
Max winding speed | 6000 RPM | 6000 RPM | 6000RPM |
Voltage | 220V/50HZ | 220V/50HZ | 220V/50HZ |
Machine Weight | about50KG | about70KG | about75KG |
Machine Dimension | 600*500*550mm | 700*650*600mm | 1120*700*680mm |
Lead time | 7-10days | 7-10days | 10-15days |
Over10-years manufacturer in winding machine, want to see more, contact me. Thank you.
This device uses a computer CNC control system to precisely locate the spindle by CPLD decoding and speed measurement. It is also equipped with a stepper motor with a constant current chopper to drive the wiring. It is fast and precise and ensures the normal operation of the equipment. It is widely used in the production system of medium and small transformers, relays, communication coils, high voltage wire packages, power converters, stabilizers, and other products.
Functions and characteristics:
1. The data stores the paragraph 0~999 step.
2. It can reverse the winding at high speed.
3. The number of circles is accurate.
4. The problem information is saved automatically.
5. CNC can monitor and display production status.
6. The setting is simple and the operation is convenient.
Model | YSY-PW762 | YSY-PW764 | YSY-PW766 |
Windable Wire Diameter | φ0.04-0.8mm | φ0.03-0.6mm | φ0.03-0.6mm |
Max.winding width | 100mm | 100mm | 100mm |
Max. bobbin Diameter | 70mm | 70mm | 100mm |
Spindles | 2 | 4 | 6 |
Spreading motor | 24V Stepping Motor | 24V Stepping Motor | 24V Stepping Motor |
Winding motor | AC 750W | AC 750W | AC 750W |
Max winding speed | 6000 RPM | 6000 RPM | 6000RPM |
Voltage | 220V/50HZ | 220V/50HZ | 220V/50HZ |
Machine Weight | about50KG | about70KG | about75KG |
Machine Dimension | 600*500*550mm | 700*650*600mm | 1120*700*680mm |
Lead time | 7-10days | 7-10days | 10-15days |
Over10-years manufacturer in winding machine, want to see more, contact me. Thank you.
